PRODUCT DETAILS
• Outstanding even grinding quality
• Wear-resistant premium burrs
• Very powerful three-phase motors with surface cooling and high starting torque - suitable for continuous operation
• Service-free, constantly greased bearings
• Two additional fans to cool the motor
• Ground material container (capacity 200 l)
Legend
- DK27 LV (Cast steel)
- DK27 LVS (Steel)
- DK27 LVH (Tungsten Carbide)
- DK27 LVT (Cast steel for turkish)
- DK27 LVST (Steel for turkish)
- DK27 LVHT (Tungsten Carbide for turkish)
TECHNICAL DETAILS
Voltage // frequencies // phases:
- 380-415 V // 50/60 Hz // 3~
- 208-220 V // 50/60 Hz // 3~
Idle speed: 980 rpm (50 Hz); 160 rpm (60 Hz)
Burr diameter: 180 mm
Burr material: Fully hardened special steel
Grind Life (median setting): ca. 10-15 tons
DK27 LV, DK27 LVT:
Fully hardened cast steel
Grind Life (median setting): ca. 15-20 tons
DK27 LVHT, DK27 LVH:
Tungsten Carbide
Grind Life (median setting): ca. 35-40 tons
Grinding capacity - fine* kg/h (approx.):
230 (DK27 LV)
260 (DK27 LVH)
280 (DG27 LVS)
Grinding capacity - medium* kg/h (approx.):
250 (DK27 LV)
280 (DK27 LVH)
300 (DK27 LVS)
Grinding capacity - turkish* kg/h (approx.):
170 (DK27 LVT)
180 (DK27 LVST)
220 (DK27 LVHT)
Bean hopper capacity: approx. 30 kg
Max. nominal power: 5500 W
Dimensions (w x h x d):
79 x 160 x 123 cm (incl. base)
69 x 70 x 79 cm l 200 l (container)
Dimensions of packing (w x h x d): Depends
on individual version and equipment
Net weight:
155 kg (incl. base)
(DK27 LV, DK27 LVS, DK27 LVT, DK27 LVST)
158 kg (incl. base)
(DK27 LVH, DK27 LVHT)
Gross weight: Depends on individual version and equipment
Standard colors: Textured, reddish grey
