Features:
Cablevey tubular drag conveyor systems are designed to move materials in a safe, clean, and efficient manner. Our cable and tube conveyors are ideal for moving materials and product blends in a dust and contamination-free environment. Our systems are ideal for conveying delicate, fragile, and specialty bulk materials through all phases of production and processes through to packaging.
Recently, in addition to our food-grade stainless steel systems, Cablevey has released a conveyor more suitable for materials that contain natural oils. Certain natural oils like those produced by peanuts and tree nuts might affect stainless steel adversely, and therefore some materials are better conveyed through our exclusive plastic tubing.
Our Clearvey™ Systems allow materials to move through our tubing with no adverse effects. These systems are designed with the same clean, efficient and gentle handling as our stainless-steel systems. Cablevey’s Clear vey™ Systems have proven to accommodate a wide range of materials beyond peanuts and tree nuts, and the clear tubing allows the user to view the material moving through the tube ensuring proper conveying. The Fe™ system offers both wet and dry tube conveyor cleaning options
With our 8” tube conveyor systems, you can expect:
• Gentle material handling
• Enclosed dust-free environment
• Easy maintenance
System Capacity:
• 8” (203.2mm) tube diameter
• Moves up to 2,000 Ft³ (56.6 M³)/hr.
• Moves up to 80,000 pounds/hr. 36,287 Kgs per hour (depending on bulk density of materials)
Options:
• Inspection video camera & conveyor monitor system
• Dry or wet cleaning options
Cablevey Product BrochureFrequently Asked Questions
How far can materials be moved?
We have conveyed materials up to 300 ft (91m), however the maximum conveying distance is ultimately determined by the type of product to be conveyed, the capacity required and the number of sweeps (directional changes) needed for the intended configuration.
Are cable conveyors custom configured for every facility?
Yes. We always include custom conveyor engineering in our quotes as production processes and facility size and configurations are highly variable. We pride ourselves in being sticklers about efficiency, savings and safety.
How do you clean the conveyor?
Each facility develops their own cleaning protocols based on the sanitation regulations and the challenges of their products. There are different methods offered to clean and sanitize your Cablevey conveyor depending on the material being moved. Our systems can accommodate a range of cleaning options including wet, dry and clean in place.
